1000 watt

Motor Power

48V15Ah

Battery Capacity

9-speed

Gear

5 levels

Pedal Assist

26*400mm

Fat Tires

Class 2

Ebike Class

Fat-HS

Fat-HS

Full suspensions for NEW TRY!
$2,599.00
$2,599.00
Color: Black
Select Frame Size: 17"
Compatible Accessories 0 Selected
Ver todos los detalles

Adventure with HS FAT

Dual suspension. Dual batteries. One savage mid-drive motor.
This is the hunting e-bike that turns “too far” into “let’s go deeper.”

From scorched fire roads to the final dash to the trailhead, it hauls gear, game, and guts without breaking a sweat—so the only thing heavier than the bike is the story you bring back.

Strap in, twist throttle, disappear.

Beyond Expectation

FAT-HS packs a 1 000 W Bafang mid-drive, 160 Nm of torque and 48 km/h top speed. The motor uses your gears—low for grunt on sand, snow or trailer-pulls, high for fast fire-road blasts—something hub drives can’t match.

General Info
Model
Fat-HS
Weight
77.1LBS
Frame
Aluminum Alloy 6061 Full Suspension
Fork
RST GUIDE 75mm Travel
Frame Style
Full Suspension
Tires
Kenda Tires 26"*4.0"
Motor
48V 1000W Bafang M615 mid motor
Motor Torque
160N.m
Display
CDC6 LCD Display
Battery
48V15Ah Standard +Optional Second Battery 14/17Ah
Controller
48V
Throttle
Thumb throttle
Charger
US standard 2.0 A smart charger
Lights
Front and rear light
Brake Rotor
EUNORAU Design 180MM Hydraulic Disc Brakes
Cassette
Shimano-11-34T
Pedals
Nylon pedal with reflectors
Chainring
42T
Saddle
Selle Royal Saddle，Height to Ground 34"-43.3"
A - Seat Tube Length
432mm (17") / 483mm (19")
B - Reach
507mm (18")
C - Head Tube Length
160mm (6.3")
D - Chain Stay
460mm (18.1")
E - Bracket Height
375mm (14.8")
F - Wheelbase
1306mm (51.4") / 1311mm (51.6")
G - Standover
780mm (30.7") / 800mm (31.5")
H - Top Tube
582mm (22.9") / 600mm (23.6")
I - Stack
425mm (16.7") / 475mm (18.7")
J - Handlebar Height
1140mm (44.9")
K - Total Length
2056mm (80.9") / 2061mm (81.1")
L - Weight
36kg (79.4lbs)

FAQs

What is the speed limit for e-bikes in your state?

Many States in the U.S. have adopted a three-class system to describe the different levels of electric bikes. The classes are as follows:

  • Class 1: pedal assist only; maximum assisted speed of 20 mph.
  • Class 2: throttle assist only; maximum motor-powered speed of 20 mph.
  • Class 3: pedal assist only; maximum assisted speed of 28 mph.

It can be clearly seen that class 1 and 2 are regulated like regular bicycles and will follow the same rules and be allowed to use the same paths and infrastructure as regular bicycles. However, because class 3 e-bikes are capable of higher speeds, they have extra regulations and require additional equipment, although, they are still technically considered a bicycle. Currently, as stated by U.S. Federal Law, class 3 e-bikes have a minimum age of 16 years old to operate and require a helmet. Class 3 e-bikes are also not allowed on standard bike paths. The reason that class 3 e-bikes are allowed to travel at speeds up to 28 mph is because the Consumer Product Safety Commission has clarified that the law does allow e-bikes to travel faster than 20 mph when using foot pedaling and the e-bike’s motor power at the same time.

How do you ride an e-bike?

If you know how to ride a classic bike, you’re all set. An e-bike just adds an electric motor, rechargeable battery, and a controller to the mix, amplifying the fun factor.

How does it work?

Simply activate the motor by pedaling or twisting the throttle. Note: Steering skills are still required!

How far does it go?

Generally, our e-bikes run 20-30 miles on a single charge. This can extend to 50-60 miles with manual pedaling.

How long does it take to get a full charge?

It takes around 3-5 hours to charge fully from 0%.
